Introduction of basic parameters and battery performance of 501235 3.7V 160mAh lithium polymer battery

Battery Model and Basic Information

The AS501235 3.7V 160mAh Lithium Polymer Battery, manufactured by Shenzhen A&S Power Technology Co., Ltd, represents a

cutting-edge solution for various electronic applications. This robust battery boasts a nominal voltage of 3.7V and an impressive capacity

of 160mAh, making it an ideal choice for devices requiring reliable and efficient power.

Battery Model: AS501235 3.7V 160mAh

Battery Type: Lithium Polymer Battery Cell or Pack

Factory Manufacturer: Shenzhen A&S Power Technology Co., Ltd

Battery Performance and Parameters

The AS501235 3.7V 160mAh battery boasts impressive performance metrics:

Typical Capacity: 160mAh

Minimum Capacity:150mAh

Voltage: Norminal 3.7V

Charge Volatage: 4.2V

Max Continous Discharge Current: 300mAh t≤5min

Max Charge Current: 160mAh 10~45℃

Continuous Discharge Current: 80mAh

Life Cycle: 10min rest period after standard charge, 0.5C discharge to a cut-off voltage of 3.0V, 10min rest period, the capacity shall be

measured after 500 cycles of standard charge and discharge at 25±5℃.

Warrenty: A&S power offers 12 months gurantee period lithium polymer battery for our clients in case of cells with defects.

Physical Features

Despite its powerful capabilities, AS501235 3.7V 160mAh maintains a compact and lightweight design:

Cell Size: 5.0*12.0*35.0mm（Thickness*Width*Height）

Pack Size: 5.2*12.5*37.5mm（Thickness*Width*Height）

Weight: Approximately 3.2g

Cycle Life: 500 times

Life Usage: 1 year

Please note that we could do customization for clients according to requirements like maxmium size, peak discharge rating and continuous

discharge rating, connector(type), wires( NTC; length), PCB protection, and applications or devices.

Safety Features

AS501235 3.7V 160mAh battery cell or pack hasn’t passed any certificatation test yet so far but A&S Power can do for customers.

Protection Mechanisms

Over-charge Protection Voltage: 4.255--4.305V

Over-discharge Protection Voltage: 4.030--4.130V

Overcurrent protection current: 1.5--3.5A

Its protection circuit can provide multiple layers protection to avoid any internal short circuit or fire danger and set different protection

mechanisms to moniter battery working efficiency.

AS501235 3.7V 160mAh battery pack has passed UN38.3 Test Report, CE and multi-safety inspections.

CE: Conformité Européenne (CE) certification is a regulatory standard that verifies certain products are safe for sale and use in the

European Economic Area (EEA). Manufacturers place a CE marking on certified products to indicate that the product complies with

European safety rules and can be traded freely within the EEA.

UN38.3: Battery chemistries that are lithium-based must undergo UN38.3 testing requirements before being transported. This testing

certifies that the batteries are safe and will not pose a safety risk during shipping over air, water, rail, or road transportation methods.

Operating Environment

The AS501235 3.7V 160mAh is designed to perform well across a wide range of environmental conditions.

Working Temperature Range

Charging Temperature: 0~+45℃ Max Charge:80mA

                                     10~45℃  Max Charge: 160mA

Discharging Temperature:-20~+60℃

Recommended storage temperature: 25±2℃,at the shipment state

Less than 1 month: -10~+45℃

Less than 3 months: -10~+35℃

Less than 6 months: -10~+30℃

Applications

The versatile AS501235 3.7V 160mAh lipo battery is ideal for numerous applications, including:

Bluetooth headsets, Bluetooth speakers, Smart digital watches, Emergency lighting and Security systems, Gas detectors, Smart water

meter, Multicamera, Medical devices, Electronic cigarette, LED Driver, Sensor etc.

Advantages

High Energy Density: The AS501235 3.7V 160mAh lipo battery offers a compact design without compromising on performance, which

is crucial for portable devices.

Lightweight Design: Weighing significantly less than traditional batteries, it enhances the overall portability of gadgets.

Durable Construction: Designed to endure multiple charge and discharge cycles, the battery ensures long-term reliability and stability.

Versatile Applications: This lithium polymer battery is suitable for a wide range of applications, including wearable tech, drones, remote

controls, and consumer electronics.

Stay tuned for more updates on the latest advancements in battery technology. For further details about the AS501235 3.7V 160mAh

lipo battery and other innovative products, visit Shenzhen A&S Power Technology Co., Ltd’s official website https://www.szaspower.com/.
